Description
Specification:
Model: XH-A105
Material: Fiber glass board + Electronic component
Input voltage: DC12-30V
Output power: 2 x 100W
Output resistance: 4-8Ω
Audio input: Bluetooth, TF card, AUX
Number of channels: 2 Channels
Output power: Max.100W
Size: app.92 x 85 x 18mm/3.62x 3.35 x 0.71in
Installation hole distance: 85.5 x 78.5mm/3.37 x 3.09in
Installation aperture: 3mm/0.12in
Color: As picture shown
Quantity: 1 Pc
Bluetooth operation instructions:
1. When the power amplifier board is connected to the power supply and the Bluetooth is not connected, the Bluetooth indicator will flash rapidly. When successfully connected, the Bluetooth indicator will stop flashing. When the song is played, the Bluetooth indicator will flash slowly.
2. Bluetooth, TF card and AUX are not supported for simultaneous input, and the system will automatically select the audio input method that was last input.
3. When the AUX is input, the power light is steady red and the blue light of the Bluetooth flashes. When the TF card is input, the power light is steady red and the blue light of the Bluetooth flashes. When the Bluetooth is input, the power light is steady red and the blue light of the Bluetooth flashes after successful connection, and it flashes when playing music.
Bluetooth/TF card volume hole:
When the audio input uses Bluetooth or TF card, you can connect the power cord to the "+ VOL -" three holes to adjust the volume and switch songs.
1. "+" and "VOL" connection: short connection to play the previous song, long connection to increase the volume.
2. "-" and "VOL" connection: short connection to play the next song, long connection to reduce the volume.
